Overview:
The housing is machined from a billet of 6061-T6 aluminum on a state-of-the-art CNC machine producing exact tolerances. For high rpm stability, a .500″ steel shaft is supported by a sealed ball bearing and a long sintered bushing. This shaft also receives a QPQ coating for friction reduction and resistance to corrosion. A precision machined reluctor is attached to the shaft which triggers the magnetic pick-up mounted in the housing. This high output magnetic pick-up is the most accurate way to trigger your ignition. Plus, with no moving parts to wear or adjust, the pick-up is maintenancefree! Just above the pick-up is MSD’s adjustable mechanical advance assembly.
Different springs and stop bushings are supplied so you can tune an advance curve to match your application. Must be used with an MSD 6, 7 or 8-series ignition.
Features:
| Year | Make | Model | Submodel | Engine Size |
|---|---|---|---|---|
| Universal |
| Brand | MSD |
|---|---|
| C.A.R.B. EO # | D-40-39 |
| Color | Black |
| Distributor Type | Magnetic Pickup |
| Emission Code | 1 |
| Product Type | Distributor |
| Warranty | Limited 1 Year Warranty |
| Brand |
MSD |
|---|---|
| C.A.R.B. EO # |
D-40-39 |
| Color |
Black |
| Distributor Type |
Magnetic Pickup |
| Emission Code |
1 |
| Product Type |
Distributor |
| Warranty |
Limited 1 Year Warranty |
| GTIN |
085132855551 |
